drilling hydraulics module
Key Features:
- Real-time calculations for ECD, bit pressure drop, BHHP, HSI, and lag times
- Accurate volume tracking: drill pipe, annulus, steel, and BHA
- Flowrate optimization for improved hole cleaning and pressure control
- Visual breakdown of pressure losses across the wellbore
- Supports both surface-to-bit and total circulation time analysis
Real-Time Calculations Monitor key hydraulic metrics during operations with high accuracy:
- ECD and bit pressure drop
- BHHP (Hydraulic Horsepower) available at the bit
- HSI (Hydraulic Impact) and pressure losses
- Lag time: surface-to-bit, bit-to-surface, and total circulation
- Volume tracking: drill pipe, annular, steel, and BHA volumes
Optimization Tools Improve drilling efficiency and hole cleaning through tailored flowrate analysis:
- Optimize pump rates based on formation and hole geometry
- Evaluate pressure distribution along the wellbore
- Identify best operating windows to reduce risks and maximize performance
- Fine-tune hydraulics without trial-and-error on the rig
Precision Drilling Starts with Smart Hydraulics
Drilling Hydraulics Module à Accurate. Reliable. Essential.
The Drilling Hydraulics Module delivers comprehensive calculations and flowrate optimization to support efficient, safe drilling. With both real-time monitoring and pre-job planning capabilities, the module helps engineers maintain effective hole cleaning, manage ECD, and ensure hydraulic energy is properly delivered to the bit. Whether you’re on-site or planning ahead, every parameter is at your fingertips.
Our Drilling Hydraulics Module offers a complete toolkit for managing and optimizing hydraulic parameters throughout the drilling process. With separate workflows for real-time monitoring and flowrate optimization, it gives engineers the insight needed to make informed, performance-driven decisions.
